| Membrane module model | NU-4500 |
| Filter mode | internal pressure type/external pressure type |
| Membrane area | 45 m² |
| Hollow fiber membrane material | PSU |
| ID/OD | OD φ1.5mm / IDφ0.9mm |
| Max.trans-membrane differential pressure; | 300 kPa (25̊C) |
| Operating temperature range | 5 ~ 40̊C |
| Service ph range | 2 ~ 11 |
| Molecular weight cut-off | 150,000 Da |
| Initial flow rate |
7 m³/h (25̊̊C, 60kPa,internal pressure) |
| Case material | U-PVC |
| Overall dimensions | 1,655 mm x φ250mm |
